Palmer PAN01 Audionomix pasīvais līnijas transformators

Standard passive DI box for line and loudspeaker levels.

Jack input with parallel “THRU” output, transformer balanced XLR output. Attenuable input sensivity, can handle both line level and speaker level singals.

Features:

• Trafosymetric XLR Output
• Input Sensitivity Adjustable
• Input impedance: 68,000 ohms
• Output impedance: 600 ohms
• Transformer ratio: 10 : 1
• Maximum output: +6 dB
• Ground lift switch
• Metal casing 110 x 73 x 42 mm

Specifications

• No. of channels: 1
• Passive/Actibe: Passive
• Transformer balanced: Yes
• Attenuator: -30 dB
• Input/Output Gain: -20 dB
• Ground lift switch: Yes
• Max Input Level: +54 dBu
• Max Output Level: +4 dBu
• Frequency Range  2K Source Imp. -1dB: 20 Hz – 20 kHz
• Input Impedance  60Hz: 60 kΩ
• Nom. Output Impedance: 600 Ω
• Housing: Steel
• Dimension: 110 x 73 x 42 mm
